Push-in tee in technopolymer for pneumatic tubing. Tube OD 6 mm. Suitable for vacuum and compressed air.
Product number: 2L22003
Log in to see prices
In stockOut of stockFew in stock
Manufacturer Part No
2L22003
Base material
Technopolymer
Diameter (mm)
6
Type
Intermediate Tee
Push-in tee for connecting pneumatic tubing. Part of the RL22 series in technopolymer, designed for tube OD 6 mm. The release bushing enables quick disconnection without tube damage and allows repeated reuse without loss of sealing.
Key Data
Tube OD: 6 mm Medium: Vacuum and compressed air Recommended tubing: PA11, PA12, Nylon 6, Polypropylene Pressure range: –0.99 to 12 bar Temperature range: –20 to +60 °C
Construction and Standards
Body and locking bushing in technopolymer Stainless steel clamping spring NBR seal
Applications
Used in pneumatic systems for connecting actuators, valves and equipment where quick and reliable assembly/disassembly is required.
