Cooler Fresh Water/Oil G1 1/2"

See datasheet for more configurations, max cooling power 5000kW and max flow 2200 l/m..

• .
• The Hybrid series is a logical further development of a shell & tube heat exchanger for a wide range of industrial applications.
• Aluminium fins, which are pushed over the tube undle, connected by force, lead to an increased heat exchange surface.
• This is why the series is so efficient.
• The hybrid-design series is able to reach a heat output up to 5000 kW with a smaller footprint than a bare tube cooler.Product features:.
• Aluminium fins ensure a larger heat exchange surface.
• Heat output capacity up to 5000 kW.
• Tube side (Water): flow rate up to 2200 l/min.
• Removable end caps for easy cleaning of the tubes.
• Max.
• pressure: oil 35 bar / water 16 bar (higher pressure on demand).
• High-quality materials.
• Tested five times during production
