Cooler, air/oil ASA0367AH11BP

Cooler, air/oil ASA0367AH11BP

ASA0367, ASA Series Air/oil cooler, Hydraulic drive 11ccm, pmax26 bar, 2bar bypass

Product number: 699400

Log in to see prices
In stock Out of stock Few in stock
Asa
Manufacturer Part No
ASA0367AH11BP
Flow (lpm)
400
Cooling capacity (kW)
1.36
Fluid type
Hydraulic oil
Noise level (dbA)
90
Working pressure (bar)
26

Air/oil cooler from the ASA Series, designed for high-performance hydraulic systems in mobile and industrial applications.

  • It is part of a robust product line known for durability, compact design, and efficient thermal management.
  • Compact and rugged design ideal for equipments like excavators, cranes and agricultural machinery.
  • General Description.
  • Model: ASA0367AH11BP Drive Type: Hydraulic motor (11 cm³/rev) Motor Power: Up to 1.60 kW Oil Pressure: Up to 48 bar Oil Flow: Up to 23 l/min Rotation Speed: Up to 2000 rpm Air Flow: Up to 2.20 kg/s Noise Level: Up to 90 dB Weight: Approx.: 56.4 kg Temperature Range: –20°C to +80°C Bypass Valve: Internal, 2 bar Compatible Fluids: Oil and water/glycol mixtures Radiator Material: Aluminum with wavy fins
