RV-DN10-G3/8-1

RV-DN10-G3/8-1 — Check Valve (20 L/min)
Check valve, line mounted valve for hydraulic circuits. Check valve, RV-DN10-G3/8-1 Zn, Crack Pressure 0,5 bar, 20 l/m, 500 bar.
Key specifications
- Interface: Line mounted
- Flow capacity: 20
- Working pressure: 500 bar
- Nominal bore: DN 10
- Port thread: G3/8

Additional information
- On request; also available with 3.1 certificate, stainless / 316, and springs up to 8 Bar Crack Pressure.
