RPES-LCN

RPES-LCN — Pressure Relief (T-10A, 95 L/min)
Pressure relief valve, cartridge cartridge for hydraulic circuits. RPES-LCN Capacity: 95 L/min. | Cavity: T-10A .
Key specifications
- Cavity / interface: T-10A, Cavity mounted
- Flow capacity: 95
- Working pressure: 350 bar

Additional information
- Pilot-operated, balanced-poppet relief cartridges are normally closed pressure regulating valves. When the pressure at the inlet (port 1) reaches the valve setting, the valve starts to open to tank (port 2), throttling flow to regulate the pressure. These valves are accurate, smooth, quiet, fast, and have low pressure rise vs. flow.
