CBCG-LJN

CBCG-LJN — Counterbalance Valve (T-11A, 60 L/min)
Motion control valve, cartridge cartridge for hydraulic circuits. 3-port counterbalance valve CBCG-LJN, Cavity: T-11A, Capacity: 60 l/min, Pilot ratio 4.5:1, Range: 140-350bar.
Key specifications
- Cavity / interface: T-11A, Cavity mounted
- Flow capacity: 60
- Working pressure: 350 bar
- Adjustable pressure range: 140–350 bar

Recommended housings / accessories
- Our recommended housing for this cartridge: ECV/S (1 cavity) or YEV/S (2 cavities)
